Product Overview

This SparkFun CO₂ Humidity and Temperature Sensor features the next-generation SCD41 photoacoustic CO₂ sensor for high-accuracy environmental readings. The SCD41 uses Sensirion's PASens^® photoacoustic measurement system that combines narrow-band IR light and a microphone inside the sensing package capable of detecting concentrations from 0 to 40000 ppm with high accuracy over 400-5000 ppm ±(40 ppm+5%). The SCD41 features an integrated temperature and humidity CMOS sensor to enhance accuracy. For additional accuracy, the SCD41 also accepts ambient pressure readings! All this functionality comes in our standard 1in. x 1in. Qwiic form factor and will seamlessly integrate into your Qwiic-based projects. However, we still routed the I²C signals out to a set of 0.1in.-spaced pins for users who prefer a soldered connection.

The SCD41 features an automatic self-calibration routine that adjusts to its sensing environment over a seven-day calibration period. For best results, Sensirion recommends taking continuous readings for at least one hour a day of 'fresh air' for the calibration period to complete. This version of the SCD4X sensors also features a one-shot measurement option, providing optimal power consumption reduction.

We've written an Arduino library to make reading the CO₂, humidity, and temperature very easy. It can be downloaded through the Arduino Library manager by searching for 'SparkFun SCD4x', or it can be found in the Documents tab above.
