STL-27L 360° DTOF LIDAR Sensor (UART, 25m)

תיאור

A compact, high-precision 360° DTOF LIDAR with 0.03-25m range, ROS compatibility, anti-glare, and FDA Class 1 safety, ideal for robots and drones.

Measuring range: 0.03~25m
Measurement accuracy:
±15mm at 0.03m-2m, standard deviation of 5mm;
±20mm at 2m-8m, standard deviation of 15mm;
±30mm at >8m, standard deviation of 25mm
Scanning angle: 360°
Scanning frequency: 10Hz
Measurement frequency: 21600 Hz
Angular resolution: 0.167° @10Hz
Operating voltage: 4.5~5.5V
Power consumption: ＜300mA @5V
Communication method: UART
Anti-ambient light: 60klux
Operating temperature: -10°C~ 50°C
Storage temperature: -30°C~ 70°C
Weight: 45g
